Working Condition & Parameters
Air inlet temp.：2～45℃
Pressure drop：≤3%P
Pressure dew point：2～10℃
Cooling: Water cooled
Cooled water temp.: 2～35℃
Cooled water pressure: 0.2-0.4MPa
Air inlet pressure：0.4～1.0MPa
Cooled water resource: Industrial circulated soft water
Standard working condition：
Air inlet temp.:38℃，
Air inlet pressure: 0.7MPa（G）
SPECIFICATION
|
Model |
Flow rate |
Refrigeration |
Water Consumption |
Power Supply |
Dimension mm |
Connection |
Weight |
|||
|
L |
W |
H |
Air |
Coolant Water |
(kg) |
|||||
|
CFKW-60N |
8 |
1.49 |
1.2 |
220V |
970 |
500 |
875 |
Rp1-1/2 |
R1 |
130 |
|
CFKW-75N |
11 |
1.74 |
1.6 |
1050 |
600 |
1065 |
Rp2 |
R1 |
185 |
|
|
CFKW-90N |
13 |
1.97 |
1.8 |
1200 |
600 |
1065 |
Rp2 |
R1 |
190 |
|
|
CFKW-100N |
15 |
2.2 |
2.1 |
1200 |
600 |
1065 |
Rp2 |
R1 |
195 |
|
|
CFKW-125N |
18 |
3.14 |
2.5 |
380V |
1200 |
600 |
1215 |
DN65 |
R1-1/2 |
250 |
|
CFKW-150N |
23 |
3.8 |
3.3 |
1350 |
600 |
1215 |
DN65 |
R1-1/2 |
290 |
|
|
CFKW-175N |
28 |
5.5 |
4 |
1450 |
750 |
1415 |
DN80 |
R1-1/2 |
380 |
|
|
CFKW-200N |
33 |
5.8 |
4.8 |
1550 |
750 |
1415 |
DN80 |
R1-1/2 |
460 |
|
|
CFKW-250N |
38 |
7.5 |
5.5 |
1650 |
800 |
1515 |
DN100 |
R1-1/2 |
520 |
|
|
CFKW-300N |
45 |
8.2 |
6.3 |
1800 |
800 |
1515 |
DN100 |
R1-1/2 |
720 |
|
|
CFKW-400N |
55 |
8.82 |
8.1 |
2100 |
975 |
1345 |
DN100 |
R1-1/2 |
820 |
|
|
CFKW-500N |
65 |
11.03 |
9.7 |
2400 |
1200 |
1520 |
DN100 |
R1-1/2 |
1080 |
|
|
CFKW-600N |
75 |
11.25 |
11.2 |
2500 |
1200 |
1520 |
DN125 |
R1-1/2 |
1150 |
|
|
CFKW-700N |
85 |
14.7 |
12.7 |
2700 |
1200 |
1680 |
DN125 |
Rc2 |
1500 |
|
|
CFKW-800N |
110 |
18.37 |
15 |
2900 |
1300 |
1750 |
DN150 |
Rc2 |
2200 |
|
|
CFKW-900N |
135 |
22.05 |
18 |
3200 |
1300 |
1750 |
DN150 |
Rc2 |
2350 |
|
|
CFKW-1000N |
160 |
28.8 |
25.5 |
2820 |
1400 |
1805 |
DN200 |
Rc2-1/2 |
2700 |
|
|
CFKW-1200N |
190 |
33.08 |
28.5 |
3000 |
1450 |
1865 |
DN200 |
Rc2-1/2 |
3100 |
|
|
CFKW-1500N |
220 |
36.75 |
34.8 |
3150 |
1450 |
1865 |
DN200 |
Rc2-1/2 |
3300 |
|
|
CFKW-1800N |
260 |
44.1 |
39.5 |
3900 |
1750 |
2030 |
DN200 |
Rc3 |
3700 |
|
|
CFKW-2000N |
310 |
55.13 |
46.5 |
4300 |
1800 |
3000 |
DN250 |
Rc3 |
4000 |
|
|
CFKW-2700N |
410 |
73.5 |
69.5 |
4500 |
2000 |
3000 |
DN300 |
DN100 |
4900 |
|
|
CFKW-3500N |
510 |
88.2 |
85 |
4800 |
2300 |
2850 |
DN300 |
DN125 |
6000 |
|
Standard of screw is in accordance with GB/T7306
Standard of flange is in accordance with HG20592
Any change of model, specification and color shall not be advised additionally, subject to the real products.
Please refer to the corresponding brochure if you order other models.
